X-770 Mechanical Testing Building
Click on the thumbnails below to see a larger version of the picture.
A southwest view of the X-770 Building five years before its demolition, June 6, 2002
A view from the west side of the X-770. The structure covered a control room and several test areas designed to evaluate equipment using UF6 gas.
The long, north and east sides of the X-770
The south and east side of the X-770. It was supported by a steel frame and had asbestos siding.
Cell enclosure for “E” test loop. The X-770 had four separately controlled test areas called test loops, containing essential parts of a typical stage used in the uranium enrichment process buildings.
Interior southeast corner vacuum pump. Some equipment, such as transformers, oil lube pits, air conditioners, and cooling vacuum pumps were removed in the 1980s for use in the process buildings.
Interior southeast corner scale and vacuum pump.
Interior cell with instrument tubing used for testing
Looking south at the center of the X-770 control room. The center area also contained a cold trap room and offices.
X-770 D&D Activities on January 31, 2007
X-770 D&D Activities on January 31, 2007
X-770 D&D Activities on January 31, 2007
X-770 D&D Activities on January 31, 2007
X-770 D&D Activities on February 1, 2007
X-770 D&D Activities on February 1, 2007
X-770 D&D Activities on February 9, 2007
X-770 D&D Activities on February 9, 2007
X-770 D&D Activities on March 5, 2007
X-770 During Pad Removal in 2010
X-770 During Pad Removal in 2010
X-770 During Pad Removal in 2010
